Perlesmith PSTVMCO4 - Step 1 Install Wheels

M8x15 bolt(x4)
M8x45 bolt(x4)
24
25
8
4
4
26
27
4
28
29
4
8
M4 washer
M6 washer
M8 washer
M4 spacer
M6/M8 spacer(5mm)
Use Tool Kit(21)
9
2
1
Step 1 Install Wheels On The Square Tube
No. Picture Description Quantity
Attach wheels (9) to the long
and short square tube (1, 2) by
using the provided wrench (21)
Turn this nut to adjust the height of wheel.
