Perlesmith PSTVS09 - Step 2 Connect TV Plate to Support Pillar; Height Adjustment Options

P5
Step 2 Connect the TV Plate [M] to Support Pillar [P]
M P
T
S
V
Front
Back
Note: There are two choices for height adjustment. You can choose your
desired height position while connecting the TV plate [M] to support pillar [P]
Connect TV plate [M] to support pillar [P] using bolts [S] and washer [T]
Note: Connect the TV
plate [M] to the front
side of the support
pillar [P] with the
bump of the TV plate
facing back side of the
stand.
The First Choice The Second Choice
