Perlick HP24ZO-4 Service Manual

ITEM
NUMBER
DESCRIPTION
01 Replacement Compressor Kit
01a Compressor, EM20
01b TSD Assembly
01c Run Capacitor, 12uf
01d Bale Strap (Not Shown)
01e Drier, (2) 1/4” I.D. Inlets & 1/8” I.D. Outlet (Not Shown)
01f 1/4” Access Valve with 1/4” O.D. Tube Extension (Not Shown)
01g Hairpin Coer Pin (Not Shown)
01h Grommet
01i 3/8” Washer (Not Shown)
02 Compressor Electricals Kit
02a TSD Assembly
Return to Table of Contents
Residential Refrigeration
and Front Venting Commercial Refrigeration
Service Manual
HA24 Low Temperature Cabinets - Condenser Compartment Service Parts
Replacement Parts Page 10-19
