Commercial Glasswasher Installation & Operation Manual
Printed in USA 17
PKHT24 Installation Guidelines
CUSTOMER NOTICE
Improper installation of this product may void the warranty on this machine. Please follow these
guidelines for recommended installation and to ensure the warranty of this model is applicable.
Glasswasher Installation Requirements
1. Machine must be level. Adjust leveling feet to accommodate uneven fl oor surfaces.
2. Drain height should not exceed maximum height of 16”. Connect supplied drain line to three-way
valve on back of machine and gravity feed to the fl oor drain.
3. Check the pressure. Recommended pressure is between 18-20 psi.
4. Water supply to machine must be a minimum 110°F.
5. A four-wire, (neutral, ground and two 110v lines) 220v single phase connection is required. There is
a six-foot cord provided with the machine. We recommend a minimum 50-amp dedicated circuit, but
you should consult your local building code requirements for proper breaker size.
Activating/Adjusting the Booster Heater
1. Booster heater must be fi lled with water prior to connecting the blue wire from high limit switch. The
high limit switch can be found by removing the front panel and locating the red button on the front of
the heater tank.
2. Once the booster heater has been connected, the thermostat should be adjusted to maintain 180°F
during the fi nal rinse cycle. The thermostat is located on the front of the booster tank and is acces-
sible by removing the front panel on the machine.
Automatic Dispensing Equipment
1. Applications utilizing automated dispensers for administering ware wash chemicals must use 110v
dispenser equipment. There is a 110v power block for installing this equipment inside the control
panel.
