Models: HP15BO, BS, RO, RS, TO, TS, HK15BO, RO, TO
Electronic Control: Dixell (XR60CX)
Defrost Style: Programmed Defrost (12 hours--15 minutes)
Cabinet Lighting: Lights are controlled through a manual on/off switch as well as
through the door switch.
Evaporator Fan: Is controlled by the door switch during Cooling Mode
LOAD COOLING MODE OFF MODE DEFROST MODE
Compressor Energized De-Energized De-Energized
Condenser Fan Energized De-Energized De-Energized
Evaporator Fan Energized
De-Energized
Energized
Models: HP15WO, WS, HK15WO
Electronic Control: Dixell (XR60CX)
Defrost Style: Off Cycle Defrost
Cabinet Lighting: Lights are controlled through a manual on/off switch as well as
through the door switch.
Evaporator Fan: Is controlled by the door switch during Cooling Mode
LOAD COOLING MODE OFF MODE DEFROST MODE
Compressor Energized De-Energized N/A
Condenser Fan Energized De-Energized N/A
Evaporator Fan Energized Energized N/A
Return to Table of Contents
Residential Refrigeration
and Front Venting Commercial Refrigeration
Service Manual
Table 8-11. HP15BO, BS, RO, RS, TO, TS, HK15BO, RO, TO Load Operation Modes
Table 8-12. HP15WO, WS, HK15WO Load Operation Modes
Electrical System Repair Instructions Page 8-21
