6
Insert for bracket G1/4 male x G1/4 female
(104820)
Bracket (104864)
Oil brush Ø20 mm G1/4 female (101396)
Mounting bracket 1-point G1/4 female (109685)
Tube connector G1/4 male for tube oØ 8 mm straight (101496)
Tube up to +80 °C oØ 8 mm x iØ 6 mm (101393)
Bracket (104864)
Tube connector G1/4 male for tube oØ 8 mm
straight (101496)
Oil retaining valve G1/4 male x G1/4 female
up to +60 °C (104862)
All oil lled perma NOVA come with an integrated oil retaining valve. They can be installed directly on a lubrication brush
without the need for an additional oil valve.
Remote installations of oil lled perma NOVA require an oil retaining valve at the lowest point of the application. This will
prevent oil leakage from the lubrication system.
Mounting of oil lled units
Direct mounting
All metal to metal connections must
be glued together with Loctite® 243™
Remote mounting
Oil brush foam up to +80 °C 40 x 30 mm G1/4i
female thread on top + lateral thread (117435)
