5.2 Settingthepartcircleangle

Infinitelyvariablebypulling(notpressing)therelevantendoftheupperorlower
springstop.Theirrigatedpartcirclehastobeadjustedbythespringstops(see
sketch).

Settingpartcircleangle

Infinitelyvariablebypulling(notpressing)therelevantendofthe
upperorlowerspringstop.


picture3



5.3 Fullcircleirrigation

Forfullcircleirrigationthespringstopshavetoberemoved.

Onlypullspringstopssofarthatyoucanslipthemeasily.
Incaseofoverstretchingthem,theycan’tbeusedagainfor
partcircleoperation.
springstop
Adjusthere

springstop
