Stiffeningribs


Attention:
Ifthesafetyscrewcan’tbetightened
up,ithitsastiffeningribofthepiston
drive!Inthiscase,thegreycoverhas
tobepulledtighter,sothatthesafety
screwpassesthestiffeningrib.


6.Maintenance

6.1 Lubricatethethreadonthesteelpipe

Whenchangingthemainnozzle,thethreadonthesteelpipeandontheO‐ringseat
shouldbecleanedandlubricated.
Thereforethenozzlecanberemovedeasilybyhandandalsopulledagain.




picture4
O‐ring
Jetpipe

nozzle
Outletnozzleforcontrolwater

