PEUGEOT 308 SW User Manual

11
i
171
PRACTICAL INFORMATION
Rear lights
1. Brake/side lights (P21/5 W).
2. Side lights (P21/5 W).
3. Fog lamp, left-hand side
(P21 W).
Reversing light, right-hand side
(P21 W).
4. Direction indicators (P21 W).
Changing bulbs
These fi ve bulbs are changed from out-
side the boot:
 remove the two light fi xing nuts,
 extract the light carefully from the
outside,
 disconnect the light connector,
 press the four tabs and remove the
bulb holder,
 turn the bulb a quarter of a turn and
change it.
To refi t, carry out these operations in re-
verse order.
If the vehicle is fi tted with the JBL
audio system, on the right-hand
side, fi rst remove the three fi xing
bolts, then move the box.
 on the right-hand side; remove the
access fl ap,
 on the left-hand side; turn the fi xing
bolt a quarter of a turn and remove
the storage box cover,
 unclip the storage box,
