Pfaff 1052 - Feeding Motion of Needle Feed (Only on PFAFF 1051 and 1181)

Adjustment
11 - 10
Fig. 11 - 09
1
2
3
3
● Bring the needle bar into the position 0.6 mm past t.d.c.
● Turn eccentric 1 (screws 2) until the adjustment pin 3 locks into place.
11.05.08 Feeding motion of needle feed (only on PFAFF 1051 and 1181)
Requirement
When the longest stitch length is set and the needle bar is positioned 0.6 mm past b.d.c.,
the needle should not move when the reverse-feed key 4 is operated.
