Adjustment
11 - 24
11.06 Adjusting the edge trimmer – 731/01
11.06.01 Zero position of the knife
Requirement
With the edge trimmer switched off, the knife should not move when the balance wheel
is turned.
● Turn crank 1 (screw 2) according to the requirement.
1
2
2
1
Fig. 11 - 23
