Is a correct spool cap used? Attach a spool cap of the right size for the actual thread
spool.
Is the stitch plate hole damaged? Change the stitch plate.
Bobbin thread breaks
Did you insert the bobbin properly? Check the bobbin thread.
Is the stitch plate hole damaged? Change the stitch plate.
Is the bobbin area clean? Clean lint from bobbin area.
Is the bobbin wound correctly? Wind a new bobbin.
Technical specification
Sewing machine
Rated voltage
230V ~ 50Hz
Nominal consumption
70W
Light
LED
Sewing speed 800 stitches/minute maximum
Machine dimensions:
Length (mm)
Width (mm)
Height (mm)
Net weight (kg)
420
210
310
5.9
Foot control
Model
C-8001
Rated voltage
DC 15V, max. 3mA
• The technical specifications and this owner’s manual
can be changed without prior notice.
