Adjustment
14 - 33
100 101 Software version main processor 0335/xxx
The software version of the main
processor is displayed
102 Software version sewing drive unit V.xx
The software version of the sewing
drive module is displayed.
103 Software version control panel V.xxx/ H.xxx
The soft- and hardware version of the
control panel are displayed.
600 601 Display inputs
With this function the digital inputs can
be checked. "IN" shows the input
numbers (1 – 16). Under "VAL" the
respective switch status is displayed.
IN VAL
1 IN1, programmable input 1
2 IN2, programmable input 2
3 E3, work clamp raised
4
5
6
7
8
9
10
11
12
13
14
15
16
602 Display special inputs
With this function it is possible to
check the special inputs pedal,
reference X (SM1) and reference Y
(SM2). "IN" shows the inputs (PED,
REFX, REFY). Under "VAL" the
respective switch status is displayed.
IN VAL
PED Pedal (speed control unit
-1; 0; +1; 2)
REFX Reference input X
REFY Reference input Y
Group Parameter Description Setting Set value
range
