Adjustment
14 - 34
600 603 Connect outputs
With this function the outlets can be
connected. "OUT" shows the outlet
selected (1-16). Under "VAL" the
selected output is set (S) with the
plus/minus key (+), and reset (R) with
the plus/minus key. Interlocks are
checked. Non-assigned outlets are not
connected.
OUT VAL
1 S/R Solenoid for work
clamp open
2 S/R
3 S/R Solenoid for
thread trimming
4 S/R
5 S/R
6 S/R Program outlet
7 S/R Program outlet
8 S/R
9 S/R
10 S/R
11 S/R
12 S/R
13 S/R
14 S/R
15 S/R
16 S/R
604 Move stepping motors
The stepping motors SM1 (X-axis) and
SM2 (Y-axis) are moved individually
with the respective plus/minus keys.
Interlocks are not checked.
605 Turn sewing motor
The sewing motor can be operated
with a selectable set speed by
pressing the pedal. After the sewing
motor has been started, the current
speed is also displayed.
606 Thread trimming sequence
The sequence for a complete thread
trimming cycle is started with the
plus/minus key (+) below CUT and
below THR.
Group Parameter Description Setting Set value
range
