Mounting and commissioning the machine
8 - 4
8.01.06 Start inhibitor (only for machines with integrated sewing motor)
Fig. 8 - 06
● For machines delivered without a table, the metal plate 1 included with the accessories
must be mounted so that it is flush with the lower edge of the table top and with the left
edge of the table top cutout (see Fig. 8.0.6).
● Insert the machine in the table top.
● After loosening screws 3, push switch 2 forwards until it touches the plate 1.
● In this position tighten screws 3.
● If the machine is tilted backwards,
switch 2 prevents the motor from
starting accidentally. "ERROR 92"
appears on display 4.
● After the machine has been placed in an
upright position, switch off the motor
with switch 5.
● When the motor is switched on again
with switch 5, the machine is ready for
operation.
Fig. 8 - 07
5
4
1
3
2
