1 Specifications for the PFAFF 3811-../..
Sewing machine head : for -2/45: .................... 5487/5489-814/01 N
for -11/43 und -11/45:.. 5487/5489-814/01
for -13/45: .................. 5487/5489-814/01-731/12
Stich type : 401
Max. s.p.m. : 3200 min
-1
Basic stitch length : 3 and 4 mm ( -2/45 2,2 mm)
Differential stitch length : 8 mm ( -2/45 6 mm)
Needle system : Leather: 4463KKD
Fabric: 4463-35
Needle size : 80 - 110 depending on material
Trimming margin : (only -13/45) 6mm
Presser foot clearance : 7mm
Sewing motor : QE 6040, Q 31 PLUS, P 40 SE, Q 40 SE
Input rating : 0,8 kW
Power supply : E 230 Volt, 50/60Hz
Working air pressure : 6 bar
Air consumption : ~0,3 - 0,5 Normlitre per work cycle
Work place related emission level : at s.p.m. n=2600min
-1
: L
pA
<79 dB(A). Noise level
measurement in accordance with DIN 45635-48-A-1
Dimensions : LxBxH (1250 x 600 x 1700mm; incl. spool holder)
Weight : Net: 140 kg
Subject to alterations Status 06.94
Fields of application
PFAFF 3811-2/45
-11/43
-11/45
Integrated sewing unit for working fullness into a material ply
PFAFF 3811-13/45
Integrated sewing unit for working fullness into a material ply with simultaneous edge
trimming
