3 Initial check
After unpacking the machine and before operating it for the first time, check that it has not
been damaged during transport.
If any damage has occurred, inform the forwarding company and your Pfaff agent immediately.
4 Installing the machine
Place the machine in the desired position on a horizontal surface.
5 Connecting compressed air and electricity
5.1 Compressed air
Connect the compressed air hose (6 mm internal diameter) to coupling 1 (diag. 1).
Minimum pressure in system: 7 bar
Working pressure: 6 bar
Pressure regulation: adjusting knob 2
5.2 Electricity
.1 The admissable working voltage (arrow in fig. 3) is indicated on the specification plate.
.2 Never operate the machine if the supply voltage and the working voltage are not the
same! (circuit diagram!)
.3 Only plug the machine into an earthed power socket.
6 Switching the machine on
.1 Open the air pressure at the main conductor.
.2 Check the working pressure: 6 bar (Manometer 3; fig. 1)
.3 Adjust if necessary (adjustment knob 2).
.4 Switch on the machine (switch 4 to “|”; fig. 2)
Note: Other switch combinations are possible.
E.g. Switch on the machine = Press the “|” key.
7 Switching the machine off
Switch 4 to “O” (fig. 2).
Note: Other switch combinations are possible.
E.g. Switch on the machine = Press the “0” key.
