6
Key panel
Potentiometer 0-15
for adjusting the fullness as
allocated to the numbered keys
Foot pedal
0 = Foot pedal resting position
+ = Foot pedal forwards
+1 = Presser foot down
s
+2 = Sewing
- = Foot pedal reverse
-1 = Presser foot up
s
, needle position
-2 = Trim thread (optional)
Presserfußposition
s
Bi02-10
On/off switch
For switching the entire
work station on and off. The
version depends on the
motor.
Quick digital motor control panel
(see technical literature from the
motor manufacturer)
Knee lever for fullness
By pressing the knee lever you achieve the following results:
on the -2/45: switching between the two fullness levels which
are set with the keys and
on the -11/43, -11/45, -13/45:
switching between the last value selected with a
numbered key and sewing without fullness.
s
= in accordance with the switch setting on
the motor control panel (see technical
literature from the motor manufacturer)
2 Operation elements and optical displays
Bi02-01
