Embroidery Mode - Preparations
Embroidery unit overview
(type BE20)
A Embroidery unit release button
B Level adjusting feet
C Embroidery unit accessory tray
D Embroidery unit socket
E Embroidery hoop connection assembly
F Embroidery arm
Note: A smaller embroidery unit, 260x200mm, is
available to purchase at your local authorized PFAFF®
dealer.
Embroidery unit accessory tray
Use the tray in the embroidery unit to store
accessories used for embroidering.
Embroidery hoop overview
G Embroidery hoop connector
H Outer hoop
I Inner hoop
J Quick release
K Retaining screw
L Ribs for À tting the clips
M Center marks
