Specifi cations
10
3 Specifi cations *
3
.01 PFAFF 2235 BASIC, PFAFF 2235 PLUS and PFAFF 2235 PREMIUM
Stitch type: .........................................................................................................301 (lockstitch)
Needle system: .............................................................................................................. 134-35
Version: ................................................................................................ CN, CN9, C/DN, C/DN9
Needle size in 1/100 mm:
Version CN, CN9: ....................................................................................................... 110 – 140
Version C/DN, C/DN9: ............................................................................................... 150 – 200
Max. stitch length:
Version CN, C/DN: ............................................................................................................6 mm
Version CN9, C/DN9: ........................................................................................................9 mm
Max.thread size (synthetic):
Version CN, CN9: ............................................................................................................. 15/3
▲
Version C/DN, C/DN9: ...................................................................................................... 10/3
▲
Presser foot clearance: ..................................................................................................20 mm
Clearance width: ..........................................................................................................350 mm
Clearance height: .........................................................................................................120 mm
Bed plate dimensions: .......................................................................................640 x 200 mm
Noise data:
Noise emission level at workplace with a sewing speed of 2400 spm: ............ L
pA
< 80 dB(A)
■
(Noise measurement in accordance with DIN 45 635-48-A-1, ISO 11204, ISO 3744, ISO
Motor data: .................................................................... See instruction manual for the motor
Leakage current ........................................................................................................... < 5 mA
◆
Air consumption per switch cycle: ...............................................................................0.146 NI
Net weight of sewing head: .................................................................................approx. 70 kg
Gross weight of sewing head : .............................................................................approx. 80 kg
3.02 Maximum speed
Top feed lift Stitch length range Max. spm on version C Max. spm on version C/D
1 - 4 mm up to 9 mm 3000 2800
4,5 mm up to 9 mm 2900 2700
5 mm up to 9 mm 2600 2400
5,5 mm up to 9 mm 2500 2300
6 mm up to 9 mm 2400 2300
6,5 mm up to 9 mm 2200 2000
7 mm up to 9 mm 2000 1800
7,5 - 9 mm up to 9 mm 1800 1600
❋
Subject to alterations
◆
Due to the use of network fi lters there is a nominal leakage current of < 5 mA.
▲
synthetic, or other sizes of comparable thread types
■
K
pA
= 2,5 dB
