6 Installation
6
.01 Setting the sewing machine into the stand
● Attach each of the hinges 1 to the sewing head with two screws M6 x 16.
● On the PFAFF 2542 and 2545/46 attach tilt lock 2 with a M5 x 6 screw
(on the PFAFF 2231 + 2235 the tilt lock is already attached)
● Set the sewing machine into the table top.
Installation
Fig. 6 - 01
1
2
1
