APPENDIX B2
Electrical and mechanical components
Please note: refrigeration circuit is located on the upper part of all Standard Chiller units and accessible by removing the two
top lateral panels (left and right sides) for all EB Chillers up to model EB150 WT.
From EB190 WT Chillers, refrigeration and hydraulic circuits – installed at the same base level – are accessible by removing the
two lateral panels.
High pressure Pressor-switch
