7
© Pfaudler GmbH
Corrosion Detector Portable CDP EXProof
4.10 Measurement
4.10.1 User
Switch the device on. The user may
enter his name in the main menu, a max.
of 50 users are possible. This entry is
made once, whenever the unit is used
again, the relevant user may select his
name from the list.
4.10.2 Test
Do not select Test unless the reactor is
ready for the measurement. The Select
test location menu is displayed. Select
New record if no measurements have
been stored in the archive yet.
If a reactor has been tested before, it
may be selected, and a new record and
index no. is generated by pressing Copy.
When New record has been selected,
the Edit location window appears. E.g.
the company, the building and the reactor
may be entered here. The Reactor line
is mandatory.
m Up to 500 locations can be
stored.
Corrosion Detector
User:.dler/Tabert
Test
Conductivity calculator
Archive
Setup
29.06.07 08:00:00
Select User
<New Entry>
Pfaudler\Schulz
Meier
Friedrich
Edit
Edit User
Company: Pfaudler
Name: Schulz
A/a ABC A/1
Select test location
<New record>
Chemical\G22\R12345
Chemical\G22\R12361
Pfaudler\G98\R12379
Pfaudler\G99\R9988
Copy
Edit
Edit location
Company: Chemical
Bldg: G22
Reactor: R12345
A/a ABC A/1
Fig. 3 Reactor with CPD
