The Pfeiffer Vacuum parameter set
Status requests
055 Cfg AO1 Configuration output AO1 0 = Actual rotation speed
1 = Power
2 = Current
3 = always 0 V
4 = always 10 V
5 = follows AI1
7RW 0 5 0 x
057 Cfg AI1 Configuration input AI1 0 = Disconnected
1 = Set value rot. speed setting mode
7RW 0 1 0 x
060 CtrlViaInt Control via interface 1 = Remote
2 = RS485
4 = PV.can
8 = Field bus
16 = E74
7RW 1 255 1 x
061 IntSelLckd Interface selection locked 0 = no
1 = yes
0RW 0 1 0 x
062 Cfg DI1 Configuration input DI1 0 = Deactivated
1 = Enable venting
2 = Heating
3 = Sealing gas
4 = Run-up time control
5 = Rotation speed setting mode
Setting ≠[P:063/064]
7RW 0 5 1 x
063 Cfg DI2 Configuration input DI2 0 = Deactivated
1 = Enable venting
2 = Heating
3 = Sealing gas
4 = Run-up time control
5 = Rotation speed setting mode
Setting ≠[P:062/064]
7RW 0 5 2 x
064 Cfg DI3 Konfiguration input DI3 0 = Deactivated
1 = Enable venting
2 = Heating
3 = Sealing gas
4 = Run-up time control
5 = Rotation speed setting mode
Setting ≠[P:062/063]
7RW 0 5 3 x
# Display Designation Functions
Data type
Access method
Unit min max default
# Display Designation Functions
Data type
Access method
Unit min max default
300 RemotePrio Remote priority 0 = no
1 = yes
0R 0 1
302 SpdSwPtAtt Rotation speed switch point attained 0 = no
1 = yes
0R 0 1
303 Error code Error code 4R
304 OvTempElec Excess temperature electronic drive unit 0 = no
1 = yes
0R 0 1
305 OvTempPump Excess temperature pump 0 = no
1 = yes
0R 0 1
306 SetSpdAtt Set rotation speed attained 0 = no
1 = yes
0R 0 1
307 PumpAccel Pump accelerates 0 = no
1 = yes
0R 0 1
308 SetRotSpd Set rotation speed (Hz) 1 R Hz 0 999999
309 ActualSpd Actual rotation speed (Hz) 1 R Hz 0 999999
310 DrvCurrent Drive current 2 R A 0 9999.99
311 OpHrsPump Operating hours pump 1 R h 0 65535 x
312 Fw version Firmware version electronic drive unit 4 R
313 DrvVoltage Drive voltage 2 R V 0 9999.99
314 OpHrsElec Operating hours electronic drive unit 1 R h 0 65535 x
315 Nominal Spd Nominal rotation speed (Hz) 1 R Hz 0 999999
316 DrvPower Drive power 1 R W 0 999999
319 PumpCylces Pump cycles 1 R 0 65535 x
324 TempPwrStg Temperature power stage 1 R °C 0 999999
