Pfeiffer TC400 User Manual

15
The Pfeiffer Vacuum parameter set
037 Cfg Acc A2 Configuration accessory connection A2 0 = Fan (continous operation)
1 = Venting valve, normally closed
2 = Heating
3 = Backing pump
4 = Fan (temperature controlled)
5 = Sealing gas
6 = always 0
7 = always 1
8 = Venting valve, normally open
7RW 0 7 3 x
038 Cfg Acc B2 Configuration accessory connection B2 0 = Fan (continous operation)
1 = Venting valve, normally closed
2 = Heating
3 = Backing pump
4 = Fan (temperature controlled)
5 = Sealing gas
6 = always 0
7 = always 1
8 = Venting valve, normally open
7RW 0 7 2 x
045 Cfg Rel R1 Configuration Relay 1 0 = Rot. speed switch point attained
1 = No error
2 = Error
3 = Warning
4 = Error and/or warning
5 = Set speed attained
6 = Pump on
7 = Pump accelerates
8 = Pumpe decelerates
9 = always 0
10 = always 1
11 = Remote priority active
12 = Heating
13 = Backing pump
14 = Sealing gas
15 = Pumping station
7RW 0 15 0 x
046 Cfg Rel R2 Configuration Relay 2 0 = Rot. speed switch point attained
1 = No error
2 = Error
3 = Warning
4 = Error and/or warning
5 = Set speed attained
6 = Pump on
7 = Pump accelerates
8 = Pumpe decelerates
9 = always 0
10 = always 1
11 = Remote priority active
12 = Heating
13 = Backing pump
14 = Sealing gas
15 = Pumping station
7RW 0 15 1 x
047 Cfg Rel R3 Configuration Relay 3 0 = Rot. speed switch point attained
1 = No error
2 = Error
3 = Warning
4 = Error and/or warning
5 = Set speed attained
6 = Pump on
7 = Pump accelerates
8 = Pumpe decelerates
9 = always 0
10 = always 1
11 = Remote priority active
12 = Heating
13 = Backing pump
14 = Sealing gas
15 = Pumping station
7RW 0 15 3 x
050 SealingGas Sealing gas 0 = off
1 = on
0RW 0 1 0 x
# Display Designation Functions
Data type Access method
Unit min max default 
