Pfeiffer TC400 User Manual

14
The Pfeiffer Vacuum parameter set
019 Cfg DO2 Configuration output DO2 0 = Rot. speed switch point attained
1 = No error
2 = Error
3 = Warning
4 = Error and/or warning
5 = Set speed attained
6 = Pump on
7 = Pump accelerates
8 = Pumpe decelerates
9 = always 0
10 = always 1
11 = Remote priority active
12 = Heating
13 = Backing pump
14 = Sealing gas
15 = Pumping station
7RW 0 15 1 x
023 MotorPump Motor pump 0 = off
1 = on
0RW 0 1 0 x
024 Cfg DO1 Configuration output DO1 0 = Rot. speed switch point attained
1 = No error
2 = Error
3 = Warning
4 = Error and/or warning
5 = Set speed attained
6 = Pump on
7 = Pump accelerates
8 = Pumpe decelerates
9 = always 0
10 = always 1
11 = Remote priority active
12 = Heating
13 = Backing pump
14 = Sealing gas
15 = Pumping station
7RW 0 15 0 x
025 OpMode BKP Operation mode backing pump 0 = Continous operating
1 = Intermittend mode
2 = Delayed switch-on
7RW 0 2 0 x
026 SpdSetMode Rotation speed setting mode 0 = off
1 = on
7RW 0 1 0 x
027 GasMode Gas mode 0 = Heavy Gase
1 = Light Gase
2 = Helium
7RW 0 1 0 x
030 VentMode Venting mode 0 = Delayed venting
1 = No venting
2 = Direct venting
7RW 0 2 0 x
035 Cfg Acc A1 Configuration accessory connection A1 0 = Fan (continous operation)
1 = Venting valve, normally closed
2 = Heating
3 = Backing pump
4 = Fan (temperature controlled)
5 = Sealing gas
6 = always 0
7 = always 1
8 = Venting valve, normally open
7RW 0 7 0 x
036 Cfg Acc B1 Configuration accessory connection B1 0 = Fan (continous operation)
1 = Venting valve, normally closed
2 = Heating
3 = Backing pump
4 = Fan (temperature controlled)
5 = Sealing gas
6 = always 0
7 = always 1
8 = Venting valve, normally open
7RW 0 7 1 x
# Display Designation Functions
Data type Access method
Unit min max default 
