45
Phantom Flex Manual
Chroma is the color component of the video signal.
1. To increase the Chroma value hold in Menu button and rotate clockwise.
2. To decrease the Chroma hold in and rotate counter clockwise.
The hue angle is adjustable both in a positive & negative value.
1. To turn the Hue more positive, hold in Menu knob and rotate clockwise.
2. To turn the Hue more negative, hold in the settings knob and rotate
counter clockwise.
Chroma
Hue
44
Phantom Flex Manual
The pedestal can be adjusted in three separate color channels, red, blue &
green.
1. To increase the red, green or blue channel, hold in Menu button and
rotate clockwise.
2. To decrease red, green or blue channel, hold in and rotate counter
clockwise.
The gamma can change be changed in individual red & blue channels.
1. To increase the red or blue amount, hold in Menu button and rotate
clockwise.
2. To decrease red or blue amount, hold in and rotate counter clockwise.
PEDR, PEDG, PEDB
GAMMAR, GAMMAB
