Phantom Miro C110 Camera Manual
BNC Connectors
Multiple signal ports
BNC
Description
Trigger Input: when a TTL pulse (rising / falling edge) is
detected, camera triggers.
SDI Output: for HD video.
Aux 1 Input / Output: switchable via PCC:
• Default setting:
- F-Sync (input / output): Connect an
external source, including the F-Sync from
a second Phantom camera, to drive the
camera’s frame rate. Use in combination
with Sync; External in the External Sync
menu.
• Available through drop-down box in PCC:
- Strobe (input): Signal goes low for the
duration of each frame’s exposure.
- Event (input): When the Event signal is
active, frames are tagged with an Event
marker (as metadata). These events can
be searched or referenced during
playback.
- Memgate (input): When Memgate signal
is active the camera stops recording into
its internal memory (frames are discarded).
Aux 2 Input / Output: switchable via PCC:
• Default setting:
- Strobe (Output): Signal goes low for the
duration of each frame’s exposure.
• Available through drop-down box in PCC:
- READY (output): When signal is high it
indicates that the camera is in capture
mode. Using PCC, signal can be set to go
low at trigger or at the end of recording.
