Chapter 7: Support
31
Miro C110 Rear View
Trigger LED
Ethernet LEDs
led indicators
A
A
B
B
COLOR CAMERA STATE
White Camera is booting up
Green Camera is in Preview mode
Red Camera is in Capture mode
Red Flashing Camera is in Trigger mode, and saving images
COLOR ETHERNET STATE
Green Ethernet Link
Amber Ethernet Activity
