Phantom Sure View SU0508L User Manual

Installing the Screen Housing Assembly
Attaching the Screen Housing Assembly
1. Place the front left corner of the Screen Housing Assembly in the outside edge of the
Mounting Bracket. (C)
2. Pivot the Screen Housing along this point until the back of the Assembly snaps into
the “L” shaped edge on the back of the Mounting Bracket.
11
Screen
Housing
Mounting
Bracket
Mounting Bracket
Screen Housing
Snap Screen Housing into “L” Shaped
Edge of Mounting Bracket
C
