Phantom Sure View SU0508L - Installing the Catch Frame; Insert and Attach Catch Frame

1. Insert the Catch Frame into the bottom of the Top Rail
End Cap. Ensure that the Top Rail End Cap ts tight to
the right side of the door frame. (D)
2. Using a level, adjust the Catch Frame along the
mounting surface of the door frame to ensure that it is
positioned plumb. It is important that the bottom of the
Catch Frame ts tight to the door sill. (E)
3. Attach the Catch Frame to the door frame using the
5/8” (16 mm) Pan Head Screws provided. (F)
Installing the Catch Frame
13
Top Rail
Catch Frame
5/8” (16 mm)
Pan Head Screw
Catch
Frame
Top Rail
End Cap
Catch
Frame
Push
Inser t
Push
D
E
F
