Chapter 4: On-Camera Controls & On-Screen Displays | 17
B
C
D
E
F
G
K
I
H
L
J
TIMECODE
BUFFER BAR WITH TRIGGER POINT
FLASH MEMORY STATUS
FRAME COUNT & DURATION
EF LENS APERTURE DATA
CINE INDICATOR
PLAYBACK
PLAYBACK BAR
PLAYBACK TIMECODE
CAMERA NAME
CAPTURE SETTINGS
Frame count and playback duration based on current video settings, within the mark-in and
mark-out points.
Indicates the IRIG timecode stamped to each frame.
This ‘timeline’ represents all frames available in camera RAM (‘Loop’ mode). The ‘T’ indicator
represents the user-defined trigger point.
Displays the frame count and recording time based on the current camera settings.
Indicates the memory size of the Phantom CineMag (if present) and the total recording time available.
Displays the f-stop (aperture) the lens. Valid for Canon EF mounts only.
Indicates user-defined camera name. If not defined, the camera serial number is displayed.
Shows frame rate, exposure time and resolution.
Indicates the Cine number selected for playback.
A visual representation of the Cine timeline with the trigger (T) point, mark-in and mark-out (|) points,
and play head indicated.
Shows the timestamp of each frame in IRIG format and the current frame number.
