Rotary Table/Lathe Chuck Adapter Plates
+
Table
221‐304 221‐306
220‐006
221‐308
220‐008
221‐310
220‐010
221‐312
220‐012
221‐316
Size 4”Table 6”Table 8”Table 10”Table 12”Table 16”Table
Plate 221‐354 221‐356 221‐358 221‐360 221‐362 221‐366
Lathe
Chuck
559‐110
3”
559‐112
5”
559‐113
6”
559‐114
8”
559‐115
10”
559‐116
12”

4”RotaryTable/4”AdapterPlate/3”LatheChuck
6”RotaryTable/6”AdapterPlate/5”LatheChuck
8”RotaryTable/8”AdapterPlate/6”LatheChuck
10”RotaryTable/10”AdapterPlate/8”LatheChuck
12”RotaryTable/12”AdapterPlate/10”LatheChuck
16”RotaryTable/16”AdapterPlate/12”LatheChuck


MountingInstructions:

Makesurethe“step”ontheadapterplategoestothebacksideofthe
lathechuck.
Connectusingmountingboltsthataresuppliedwiththelathechuck.
Carefullyplacetheplate/chuckassemblyontherotarytablefaceplate
andlineuptheholesintheadapterplatewiththeT‐slotsontherotary
table.ConnectusingtheT‐nutsandboltsthataresuppliedwiththe
adapterplate.
Centertheplateandtightenbolts.
+
=
