OperatingInstructions&PartsManual
 HorizontalRotaryTables
 DividingPlates
Pg. 2
Operating Instructions & Parts Manuals
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product
described. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal
injury and or property damage! Retain instructions for future reference.

Description
ThePhaseIIhorizontalrotarytablesareusedfor
indexing,circularcutting,anglesetting,boringand
spotfacingoperations.Themeehanitecastiron
tableisprecisionmachinedandisprovidedwitha
MorseTapercenterhole.Thetableisgraduated
witha360scale.Amicrocollargraduatedtoone
minutewithatensecondaccuracyvernierscaleis
provided.Rotarytablefeaturesincludelock‐down
handlesandcrankdisengagementmechanism.

Wormgearandcenterholetaperarehardened
andground.Thedividingplatesaccessoryallows
theoperatortoaccuratelydividethe360rotation
oftheclampingsurfaceintodivisionsof2through
66,andalldivisiblesof2,3and5from67‐132.
Unpacking
Checkforshippingdamage.Ifdamagehasoccurred,a
claimmustbefiledwithcarrierimmediately.Checkfor
completeness.Immediatelyreportmissingpartsto
dealer.Carefullyremovetablefromcrate.
Important:Thetoolhasbeencoatedwithprotective
coating.Inordertoensureproperfitandoperationthe
coatingmustberemoved,removecoatingwithmild
solventssuchasmineralspiritsandasoftcloth.
Nonflammablesolventsarerecommended.After
cleaning,coverallexposedsurfaceswithalightcoating
ofoil.Besuretolubricatetableasdescribedin
"Maintenance"
Caution:Neverusehighlyvolatilesolvents.
Avoidgettingcleaningsolutiononpaint,asit
maytendtodeterioratethesefinishes.Use
soapandwateronpaintedcomponents.

Specifications
DividingPlatesAccessory
Possibledivisionsof
Onerotation:...................2thru66,andall
...............................................divisiblesof2,3,and5
...............................................from67‐132





Accuracy  MaximumT.I.P.
Flatnessofclampingsurface.............................0.0006”
Parallelismofclamping
Surfacetobase.......................................................0.0008”
Squarnessofclampingsurface
toangleface............................................................0.0004"
Squarenessofclampingsurface
tocenterslot...........................................................0.0008"
Concentricityofcenterbore..............................0.0008"
Maximumspacingerror:
6”&8”.....................................1minute,20seconds
10”,12”&16”.........................45seconds
GeneralSafetyInformation
1. Readandfollowalloperatinginstructionbeforeoperating
rotarytable.
2. Understandandobeyallsafetyinstructionssuppliedwithmill
orothermachinesonwhichtherotarytableisused.
3. Alwayssecurerotarytabletoworksurfaceorothermachine.
4. Alwayssecureworkpiecetorotarytableclampingsurfaceif
used.
5. Alwayssecurefaceplatetorotarytableclampingsurfaceif
used.
6. Alwayssecurerotarytableclampingsurfacewithlock‐down
handleswhenpossible.
7. Maintainandlubricatetoolproperly.









Installation
1. Mountrotarytablesecurelytomachineworksurface.
2. Useslotsprovidedontableandbesurethattableis
rigidlyandsafelysecured.
3. Tablecanonlybemountedhorizontallywithslots
provided.
Lubrication
Keeprotarytablecleanofdirtorchips.
Beforeputtingintouse,fillbasecavitywith
oilusingtheoilzertsonbase,tableandoil
plug(RefNo.11).UnscrewoilPlugpriorto
lubrication.Beforeeveryshiftofoperationfill
adequateoilthroughoilzertsandoilplug.
LUBRICATEWITHLIGHTDUTY
HYDRAULICFLUIDORSPINDLEOIL.Table
shouldbefilledwithoiluntilititvisiblein
thesightglass,donotoverfill.
Frequentlycheckoillevelusingsightglass
(Ref.No.8)Donotuserotarytablewithout
adequateoil.
