Programming Tip
To interrupt the countdown and allow a restart, push and hold both the UP and DOWN keys for one
second. The load will start immediately.
When the drive reaches the limit of faults set by the adjustable parameter, it will remain OFF and the display
will indicate the type of fault on the top line. The second line will read RESTART? ENTER. Press ENTER to
clear the fault and restart the load. The fault counters in the 5 Restart Log will all be reset to zero. See Section
3.6 for more information. Some faults do not allow auto restart. The display will read NO AUTO RESTART.
See Section 3.7, Fault Log, for more information.
4.4 All Parameters List
To aid in troubleshooting, a numbered parameter list containing all parameters is available for use. Some
parameters are visible that are not always used. In this case, the word “Disabled” is shown, and programming
functionality is disabled for that parameter. To access 1.7 ALL PARAMETERS:
1. Press the HOME key to access Main Menu items, and then scroll with arrow keys until 1 CHANGE
PARAMETER VALUES appears on the display.
2. Press ENTER to access this menu item.
3. Use the UP and DOWN arrow keys to scroll to 1.7 ALL PARAMETERS.
4. Press ENTER to access this menu item.
4.5 Changed Parameter List
This is a list of all parameters that have been changed from their default values. This allows for quick and easy
programming of previously changed parameter values. The total number of changed parameters and the index
of changed parameters will be displayed at the top of the screen. If there are no changed parameters, then
“No Changed Parameters” will be shown. To access
1. Press the HOME key to access Main Menu items, and then scroll with arrow keys until 1 CHANGE
PARAMETER VALUES appears on the display.
2. Press ENTER to access this menu item.
3. Use the UP and DOWN arrow keys to scroll to 1.8 CHANGED PARAMETERS.
4. Press ENTER to access this menu item.
4.6 File System
DXL and LHX Series products are equipped with an SD card terminal that can be used to Import and Export
Parameters as well as install firmware upgrades or custom firmware. SD cards must be Micro SD or SDHC
type, 32 GB or smaller, and formatted as FAT16 or FAT32. Firmware files will be .hex format and parameter
data files will be saved as a .CSV file.
CAUTION: SD card must be inserted while drive is powered off. Failure to do so may result in injury or
damage to the product. Power may be applied while SD card is inserted, but the system must be powered off
before removing the SD card from the terminal. Always turn power to the system off and wait for the discharge
time specified on the front label to allow the DC bus to discharge before working in the enclosure.
