Phase LHX Series - DXL Single Phase Input Voltage; DXL Voltage Doubling

80 | P a g e
Model
Frame
Size
Rated HP
(kW)
Rated Input Voltage
(1)
Rated Output
Voltage
(3)
Rated
Input/Output
Current
DXL440
D1
40 (30)
200-460 V, 3-phase
0-V
IN
, 3-phase
61 A
DXL450
D1
50 (37)
200-460 V, 3-phase
0-V
IN
, 3-phase
77 A
DXL460
D3
60 (45)
200-460 V, 3-phase
0-V
IN
, 3-phase
86 A / 91 A
DXL475
D3
75 (55)
200-460 V, 3-phase
0-V
IN
, 3-phase
101 A / 107 A
DXL4100
D3
100 (75)
200-460 V, 3-phase
0-V
IN
, 3-phase
134 A / 142 A
DXL4125
D3
125 (90)
200-460 V, 3-phase
0-V
IN
, 3-phase
163 A / 172 A
DXL4150
D3
150 (110)
200-460 V, 3-phase
0-V
IN
, 3-phase
188 A / 198 A
DXL4200
D3
200 (150)
200-460 V, 3-phase
0-V
IN
, 3-phase
237 A / 250 A
DXL4250
D3
250 (185)
200-460 V, 3-phase
0-V
IN
, 3-phase
288 A / 304 A
DXL4300
D4
300 (220)
200-460 V, 3-phase
0-V
IN
, 3-phase
346 A / 365 A
DXL4350
D4
350 (260)
200-460 V, 3-phase
0-V
IN
, 3-phase
394 A / 415 A
DXL4400
D4
400 (300)
200-460 V, 3-phase
0-V
IN
, 3-phase
454 A / 478 A
DXL4500
D4
500 (375)
200-460 V, 3-phase
0-V
IN
, 3-phase
560 A / 590 A
(1) Single Phase Input Voltage will result in 50% decrease in Rated Output Current compared to Input Current, see
section 9.2.1 DXL Single Phase Input for more information. Single phase and 3-phase input voltage is
acceptable.
(2) DXL Series Voltage Doubling drives require single phase input voltage. See section 9.2.2 DXL Voltage
Doubling for more information.
(3) V
IN
refers to input voltage.
9.2.1 DXL Single Phase Input Voltage
For the DXL Series drives, when supplied with single-phase input voltage, the rated output current
experiences a 50% decrease relative to the rated input current. Note: Interface Parameter 1.3.19 ENABLE
1PH INPUT must be configured to “Yes” when single phase input voltage is supplied to a DXL drive.
To illustrate, consider the DXL007 drive with a single-phase 230 V input voltage, which will yield a 3-phase
230 V output voltage at a current rating of 12 A, which is 50% of the rated output current, shown in Table 32.
9.2.2 DXL Voltage Doubling
For the DXL Series Voltage Doubling drives (i.e. DXL210), single-phase input voltage is required. The 3-
phase output voltage will be approximately double that of the input voltage. Note: Interface Parameter 1.3.19
ENABLE 1PH INPUT is not an applicable parameter for DXL Series Voltage Doubling drives.
To illustrate, consider the DXL210 drive with a single-phase 230 V input voltage with a 64 A input current,
which will yield a 3-phase 460 V output voltage at an 18 A output current, shown in Table 32.
