6CP100/50-10
5-1
SECTION 5: OPERATIONAL VERIFICATION PROCEDURE
1. Make sure that Main Power Circuit Breaker on the Control Panel is in OFF position.
2. Make sure that all electrical connections have been properly made between the Controls and High
Voltage Unit, including grounds. Remove Ground from HV Transformer output if it is grounded. There
is to be no connection to the high voltage outputs at this time. There must be adequate clearance from
the High Voltage Unit to allow voltage to be raised safely.
3. Place currentmeter in RTN mode. (Connect jumper of RTN/GND/GRD binding posts between RTN
and GND.)
4. Connect Main Input Power Cable to Controls and to Power Source. Switch the Main Power Circuit
Breaker on the Control Panel to On position. Main Power indicator lamp should illuminate. Check that
the Transformer Power Breaker is on, Emergency Off button is pulled up, Voltage Control is at Zero,
Reset Lamp is Off, and EXT INTLK CKT is complete or has shorting jumper in place. HV Off lamp
should be illuminated.
5. Press HV On switch. Indicator lamp should illuminate. Press the HV Off switch. HV On indicator lamp
should extinguish and HV Off / Ready lamp should illuminate.
NOTE: The following conditions must be met before High Voltage will engage: External Interlock loop
must be closed, Emergency Off switch must be closed (mushroom button up), Overload Reset Lamp
must be off, Voltage Control at Zero Start, and Transformer Power Circuit Breaker on.
6. Set Measurement Divider Switch to 100 kV / 100 mA
7. Press the HV On switch.
8. Manually raise the Voltage Control dial on the Control Panel to approximately 50 (50%). Voltmeter
should indicate voltage change, and show approximately 45 to 55 kV.
9. Select 50 kV / 200 mA on Measurement Divider Selector Switch. At 50 on Voltage Control Dial,
voltmeter should read approximately 22 to 28 kV.
10. Return Voltage Control to Zero. Press HV Off switch.
11. Turn Main Power Circuit Breaker off and connect a short between the 50kV High Voltage Output and
Ground. Measurement Divider Switch is to be set at 50 kV / 200 mA.
12. Set Overcurrent Trip to low (1) setting.
13. Turn Main Power Circuit Breaker on. Press HV On switch and slowly raise voltage with the dial on the
Control Panel. Output Current Meter will indicate changed value, and at approximately 10% of output
current rating, the High Voltage will trip off and the Overcurrent Indicator Lamp will illuminate. With the
front panel Overload Selector Switch set at 50 kV/200 mA, the trip point should be at approximately 20
mA. Return Voltage Control to zero and turn off Main Power Circuit breaker.
WARNING:
This equipment should only be used by personnel familiar with High Voltage testing and safety
procedures.
