C) TANK TYPE 40 - DFS (former software: tank type 35)
If the tank type 40 (flow sensor DFS) is preset for tank 1 or 2, the following symbol is shown in the
basic display:
after filling-up of the tank you can fill-up the shown content according to the filling in steps
of 5% by long-pressing (ca. 5s) of the button.
If there`s water flowing through the flow sensor DFS and the tank is filled, this is shown
by a rotating bar. If the tank is empty, the bar doesn`t rotate.
ADJUSTING THE ALARM
You can adjust the alarm threshold for each tank separately.
Alarm duration 0 s Alarm off
1... 600 s Alarm duration 1... 600 seconds
601 s Alarm open end, until it will be acknowlegded by pressing a button
or if the measured value has changed so that the alarm is cancelled.
Alarm level 0 % Alarm off
1..50 % Empty-alarm: if the level falls below the adjusted threshold the
alarm will be activated. The activation is delayed by 15s.
51... 99 % Full-alarm: if the level rises above the adjusted threshold the alarm
will be activated. The activation is delayed by 15s.
POWERSAVE- MODE (PS)
The Powersave mode (PS) is only for the use with ultrasonic sensors UTV, or other active sensors, because
these sensors have a power consumption of ca. 50 mA of each sensor.
If the Powersave mode is activated in the SETUP, there`s the
sign “PS” down to the right.
ATTENTION!
In the Powersave mode the alarm is switched off!
k
TANKMONITOR TCM4
Page 10 V2.3 - August 2011
