5. HANDLING
When pressing the push buttons the display light is lit during 60 s. If you connect the terminal “Light” to the
power supply via the power distribution panel the light can be activated manually.
The alarm can be acknowledged by pressing a button.
Following actions are activated by pressing:
Button 1 Button 2 Button 3 Button 4
Button 1 Long pressing (3s) Tank is being filled up in 5% steps until the maximum
value (Only if tank1: Tanktype 40 - Flow sensor DFS)
Button 2 Long pressing (3s) Tank is being filled up in 5% steps until the maximum
value (Only if tank1: Tanktype 40 - Flow sensor DFS)
Button 3 Short pressing (2
s) “SETUP”- menu available; when the display is blinking,
release the button
Long pressing (5s) Setup-menu is locked / unlocked
Button 4 no function
5.1. SETUP
In the SETUP-menu all adjustments can be changed:
Following is the key function:
Arrow: selection of the line to be modified
Plus: increase the value
Minus: decrease the value
Return: save the values and return to the
tank display
k
TANKMONITOR TCM4
Page 6 V2.3 - August 2011
