TANKMONITOR TCM4
6. TROUBLESHOOTING
If the tankmonitor shows wrong values or (---), please check first the sensor and the correct connection of the
sensor. Check also the wiring between the sensor and the tankmonitor. This is the main source of defect.
If the shown values are totally implausible, check the supply voltage of the sensors. The supply voltage has
to be min. 10V (see the data sheet of the sensor).
7. MAINTENANCE
The tank does not request special maintenance. The frontpanel can be cleaned with a damp cloth without
using agressive detergents.
8. TECHNICAL DATA
Power supply DC 10-30 Volt
Power consumption ca. 8mA when using resistance sensors,
60
mA if the display is lit (12V)
12mA when using a flow sensor DFS
when using ultrasonic sensors UTV:
50
mA per sensor (without Powersave mode)
Dimensions: 105 x 105 x 40 mm
Installation cutout: 88 x
88 mm
9. CE-CONFORMITY
philippi elektrische systeme gmbh
Neckaraue 19
71686 Remseck am Neckar
Germany
certifies herewith, that the product: Tankmonitor TCM 4
fulfills the requirements of the European Regulation EMC 89/336/EEG “electromagnetic compatibility” and
the amendments to 92/31/EEG and 93/68/EEG.
Following harmonised standards were implemented:
Emission: EN 50081-1:1992
Immunity: EN 50082-1:1992
Remseck, May 2009
Dipl.-Ing. Michael Kögel
general manager philippi
Page 12 V2.3 - August 2011
