Engineering Specification
PHILIPS Confidential – Do Not Copy 105S5
Transportation conditions
Test Item Test Condition
1. Packaged Test
Packaged random vibra. Test
2 Set
*5~200Hz, 0.73 Grms
30min/axis, 3 axes
Drop test
(After random vibra. Test)
2 Set
* Gross weight Drop height
1~9.52 kg 91 cm
9.53~18.59 kg 76 cm
18.60~27.66 kg 61 cm
27.67~45.36 kg 45 cm
* Sequence: 1C-3E-6F
Cold drop test
2 Set
* -10 degree C for 16 hours
* Gross weight Drop height
1~9.52 kg 76 cm
9.53~18.59 kg 61 cm
18.60~27.66 kg 45 cm
27.67~45.36 kg 30 cm
* Sequence: 1C-3F
2. Unpackaged test
2.1 Operating random vibra. Test *5~500Hz, 0.25 Grms
30min/axis, 3axes
2.2 Shock test (half sine wave)
2 set
*120 G, <3 msec, 6 Shocks
# exclude CRT impurity
5.2 Display disturbances from external environment
5.2.1 ESD Disturbances
According to EN50082-1 (also refer to IEC801-2 for detail).
15kV for air
8kv for contact
5.3 Display disturbances to external environment
The disturbances induced by the display and tolerated by the environment are defined as follows:
5.3.1 Ionizetic radiation
Completely fulfilled International Commission of Radio logical Protection (ICRP) requirement 0.5 mR/Hr.
5.3.2 EMI/EMS
Can comply with FCC part 15, DOC C108.8 and EN55022
EMS EN61000-4-3 (80% 1KHz AM modulation) Picture jitter ≤ 6mm
6 Physical specification
6.1 Dimension
Height: 374 mm
Width 363 mm
Depth 398 mm
Monitor weight 12.5 Kg.
6.2 Mechanical adjustment
Tilt angle: 5 degree forward and 15 degree backward
Swivel rotation: 90 degree leftward or rightward
6.3 Packaging
6.3.1 Carton dimension
Height 403 mm
Width 458 mm
Depth 469 mm
6.3.2 Shipping weight 14 Kg
6.3.3 Container loading 600 units with pallet.
