Philips 105S5 - Electrical and Environmental Specifications

Engineering Specification
PHILIPS Confidential – Do Not Copy 105S5
II-2
2.3 Scanning frequency
2.3.1 Horizontal 30KHz to 56KHz
2.3.2 Vertical 50Hz to 120Hz
3. Adjustment control
3.1 User control
3.1.1 Power switch
3.1.2 OSD key
MENU Menu button
 Enter / select button
- Down / Decrease button
+ Up / Increase button
3.2 OSD adjustment function
Contrast / Brightness / Input Level / Reset
Zoom / H-position / H-size / V-position / V-size / Reset
Pincusion / Pinbalance /Trapezoid / Parallelogram
9300
o
K / 6500
o
K / User R G B
English /Francais /Espanol /Traditional Chinese / Simplified Chinese
H-Moire / V-Moire / OSD H-Position / OSD V-Position /
3.3 LED indication.
Status LED
Normal Green
Power saving Yellow
Power on
Over range frequency Yellow
Power off Off
4 Electrical specification
A Electrical specification
4.1 Standard condition of measurement
4.1.1 Brightness – 50% factory shipment condition
4.1.2 Contrast – 100% factory shipment condition MAX
4.1.3 Other SW – Factory shipment condition
4.1.4 Background color – Black
4.1.5 Brightness 30FL Full white
4.1.6 Temperature 0~40 °C humidity 10 ~ 90% non-condensing
4.1.7 Power input –AC 90~264V 50Hz / 60Hz
4.1.8 Terrestrial magnetic field – Northern hemisphere magnetic field
4.1.9 Warm up time – Start testing 30 minutes or more after power on
4.1.10 Timing chart – Refer to item 7.2.
4.1.11 Ambient lighting environment – 400 to 600lux
4.1.12 CRT face to east
