Philips 105S5 - Factory Preset Timing

Engineering Specification
PHILIPS Confidential – Do Not Copy 105S5
II-8
7. Factory preset timings
7.1 Timing diagram
Video
D
C E
A
B
Video
R
Q S
O
P
Sync Sync
Horizontal
Vertical
Sync Polarity : Positive / Negative
