Engineering Specification
PHILIPS Confidential – Do Not Copy 105S5
II
Engineering Specification
1 Scope
1.1 This specification defines the performance of 105S5 15 inch multisync color monitor
1.2 Product configuration
TBD
1.3 Magnetic requirements
The monitor is aligned in a magnetic cage having the following magnetic field components :
Northern Hemisphere: H = 0, V = 450 mG, Z = 0
Southern Hemisphere: H = 0, V = -500 mG, Z = 0
Equator Hemisphere: H = 0, V = 0 mG, Z = 0
2 Input requirements
2.1 AC power supply
2.1.1 Main voltage 90~264VAC 47/63Hz
2.1.2 Power consumption 75W Max.
2.1.3 Inrush current < 30Ap. for 1/2 cycle at 100V
< 60 Ap. For 1/2 cycle at 240V on cold starting
2.1.4 Input current 1.5 A Max in 110V
2.1.5 Leakage current 3 mA at AC 100V/240V
2.1.6 Ripple / noise Should not cause any visible interference
2.1.7 Power cord Length: 1.5 m +50mm (exc. Connector)
Color: T color for T color cabinet, Black for Black cabinet
2.1.8 Signal Cable 1.5 m + 50mm flying with 15 pin D-shell socket
2.2 Video interface
2.2.1 Input signals
Video: Analog level
Sync: Separated sync. with TTL level
Polarity: Positive or negative
2.2.2 Signal input level
Video: 0.7 Vp-p 75 ohms (for individual of R,G and B signals must not deviate 0.015 Vp -p from each other
for balance of white pattern)
Sync: TTL level (between 0 and 0.6 V to be considered as low level, between 2.3 and 5.0 V as high level)
2.2.3 Impedance
Video: Terminated with 75 ohms
Sync: Terminated with 4.7K ohms pull down resistors.
2.2.4 Video input cable
15 pin D-shell male connector type AMP 211350-1 (3 rows) or equivalent.
Pin No. Signal Pin No. Signal
1 Red 9 5 V.
2 Green 10 Ground
3 Blue 11 Ground
4 Ground 12 SDA
5 D-
13 H. Sync
6 R Return 14 V. Sync
7 G Return 15 SCL
8 B Return
2.2.6 Signal memory modes 6 preset modes, 9 user modes see item 7.2
2.2.7 Plug & play VESA DDC1 / 2B
