Philips 14PV135 - Page 63

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
14PV385/39 14PV135/07 14PV235/01 14PV235/58 14PV385/07 14PV135/01 14PV135/58 14PV235/07 14PV385/01
R553 CARBON RES. 1/4W J 22K OHM 111111111
R554
h
9965 000 22680 CARBON RES. 1/4W J 1K OHM 111111111
R555 CARBON RES. 1/4W J 8.2 OHM 111111111
R556 CARBON RES. 1/4W J 8.2 OHM 111111111
R557
h
9965 000 09896 CARBON RES. 1/4W J 10K OHM 111111111
R558
h
PCB JUMPER D0.6-P5.0 111111111
R559
h
9965 000 19516 CARBON RES. 1/4W J 1 OHM 111111111
R560
h
9965 000 19516 CARBON RES. 1/4W J 1 OHM 111111111
R561
h
9965 000 24191 CARBON RES. 1/4W J 2.2 OHM 111111111
R564
h
9965 000 14871 CARBON RES. 1/4W J 6.8K OHM 111111111
R565 PCB JUMPER D0.6-P5.0 111111111
R566 CARBON RES. 1/4W J 470 OHM 111111111
R568 CARBON RES. 1/4W J 1.5K OHM 111111111
R569 CARBON RES. 1/4W J 270 OHM 111111111
R572 CARBON RES. 1/4W J 390 OHM 111111111
R574 CARBON RES. 1/4W J 1K OHM 111111111
R576
h
9965 000 24192 CARBON RES. 1/4W J 39 OHM 111111111
R577
h
9965 000 24193 METAL OXIDE FILM RES. 2W J 560 OHM 111111111
R578
h
9965 000 24192 CARBON RES. 1/4W J 39 OHM 111111111
R579
h
9965 000 19602 CARBON RES. 1/4W J 100K OHM 111111111
R580
h
9965 000 24192 CARBON RES. 1/4W J 39 OHM 111111111
R581 CARBON RES. 1/4W J 100K OHM 111111111
R583 PCB JUMPER D0.6-P5.0 111111111
R584
h
9965 000 22680 CARBON RES. 1/4W J 1K OHM 111111111
R585
h
9965 000 22662 CARBON RES. 1/4W J 180K OHM 111111111
R586 CARBON RES. 1/4W J 56K OHM 111111111
R587 CARBON RES. 1/4W J 56K OHM 111111111
R588
h
9965 000 22684 CARBON RES. 1/4W J 22K OHM 111111111
R589
h
9965 000 09896 CARBON RES. 1/4W J 10K OHM 111111111
R590
h
9965 000 22674 METAL OXIDE FILM RES. 2W J 2.2 OHM 111111111
R591
h
9965 000 22684 CARBON RES. 1/4W J 22K OHM 111111111
R592
h
9965 000 09896 CARBON RES. 1/4W J 10K OHM 111111111
R593 CARBON RES. 1/4W J 8.2K OHM 111111111
R594 CARBON RES. 1/4W J 2.2K OHM 111111111
R595 PCB JUMPER D0.6-P5.0 111111111
R596 CARBON RES. 1/4W J 8.2 OHM 111111111
R597
h
9965 000 24194 CARBON RES. 1/4W J 220K OHM 111111111
R598
h
9965 000 22667 CARBON RES. 1/4W J 56K OHM 111111111
R601
h
9965 000 22668 ANTI-SURGE RESISTOR 1/2W J 3.3M OHM 111111111
R602
h
9965 000 22668 ANTI-SURGE RESISTOR 1/2W J 3.3M OHM 111111111
R603
h
9965 000 22668 ANTI-SURGE RESISTOR 1/2W J 3.3M OHM 111111111
R604
h
9965 000 24195 CEMENT RESISTOR 5W J 1.8 OHM 111111111
R605 CARBON RES. 1/4W J 56 OHM 111111111
R611 CARBON RES. 1/4W J 220 OHM 111111111
R612 CARBON RES. 1/4W J 220 OHM 111111
R612 CARBON RES. 1/4W J 180 OHM 1 1 1
R613 CARBON RES. 1/4W J 390K OHM 111111
R615 CARBON RES. 1/4W J 1.5K OHM 111111
R615 CARBON RES. 1/4W J 1K OHM 1 1 1
R616
h
9965 000 22663 CARBON RES. 1/4W J 22 OHM 111111111
R617
h
9965 000 14278 CEMENT RESISTOR 5W J 0.68 OHM 111111111
R618 PCB JUMPER D0.6-P5.0 111111111
R619 CARBON RES. 1/4W J 1.2K OHM 111111111
R620
h
9965 000 24196 CARBON RES. 1/4W J 820K OHM 111111111
R621 CARBON RES. 1/4W J 560K OHM 111111111
R622 CARBON RES. 1/4W J 680K OHM 111111111
R624 CARBON RES. 1/4W J 680K OHM 111111111
R625
h
9965 000 15270 CARBON RES. 1/4W J 1.2K OHM 1 1 1
