Philips 14PV135 - Page 64

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
14PV385/39 14PV135/07 14PV235/01 14PV235/58 14PV385/07 14PV135/01 14PV135/58 14PV235/07 14PV385/01
R626
h
9965 000 15270 CARBON RES. 1/4W J 1.2K OHM 111111111
R627 PCB JUMPER D0.6-P5.0 111111111
R628
h
9965 000 19514 CARBON RES. 1/4W J 820 OHM 111111111
R631
h
9965 000 22687 CARBON RES. 1/4W J 33K OHM 111111111
R632
h
9965 000 09896 CARBON RES. 1/4W J 10K OHM 111111111
R633
h
9965 000 19518 CARBON RES. 1/4W J 15K OHM 111111111
R634
h
9965 000 19518 CARBON RES. 1/4W J 15K OHM 111111111
R635
h
9965 000 22682 CARBON RES. 1/4W J 180 OHM 111111111
R636
h
9965 000 14870 CARBON RES. 1/4W G 1K OHM 111111111
R637
h
9965 000 23547 CARBON RES. 1/4W G 5.6K OHM 111111111
R638
h
9965 000 23549 CARBON RES. 1/4W G 39K OHM 111111111
R639
h
9965 000 23549 CARBON RES. 1/4W G 39K OHM 111111111
R640
h
9965 000 22686 CARBON RES. 1/4W J 2.7K OHM 111111111
R641
h
9965 000 24197 METAL OXIDE FILM RES. 1W J 1K OHM 111111111
R642
h
9965 000 09896 CARBON RES. 1/4W J 10K OHM 111111111
R643
h
9965 000 22686 CARBON RES. 1/4W J 2.7K OHM 111111111
R644
h
9965 000 22686 CARBON RES. 1/4W J 2.7K OHM 111111111
R645
h
9965 000 22667 CARBON RES. 1/4W J 56K OHM 111111111
R646
h
9965 000 22660 CARBON RES. 1/4W J 15 OHM 111111111
R647
h
9965 000 22686 CARBON RES. 1/4W J 2.7K OHM 111111111
R649
h
9965 000 22688 CARBON RES. 1/4W J 390 OHM 111111111
R651 CARBON RES. 1/4W J 100 OHM 111111111
R652
h
PCB JUMPER D0.6-P15.0 111111111
R653
h
9965 000 22681 CARBON RES. 1/4W J 150 OHM 111111111
R654
h
9965 000 22664 CARBON RES. 1/4W J 2.2K OHM 111111111
R655 CARBON RES. 1/4W J 5.6K OHM 111111111
R656 CARBON RES. 1/4W J 47K OHM 111111111
R657
h
9965 000 22683 CARBON RES. 1/4W J 220 OHM 111111111
R658
h
9965 000 22670 METAL OXIDE FILM RES. 2W J 10K OHM 111111111
R659
h
9965 000 22670 METAL OXIDE FILM RES. 2W J 10K OHM 111111111
R660 PCB JUMPER D0.6-P5.0 111111111
R661 CARBON RES. 1/4W J 1.8K OHM 111111111
R662 CARBON RES. 1/4W J 820K OHM 111111111
R663 CARBON RES. 1/4W J 47 OHM 111111111
SW601
h
9965 000 13902 POWER SWITCH SDKVA30100 111111111
BC551 9965 000 13874 BEAD INDUCTORS FBA04HA600VB-00 111111111
BC602 9965 000 13875 BEAD INDUCTORS FBR07HA121TB-00 111111111
BC604 PCB JUMPER D0.6-P5.0 111111111
BC605 PCB JUMPER D0.6-P5.0 111111111
MISCELLANEOUS
CL501A 9965 000 18126 LEAD WIRE 3P/230 111111111
F601
h
9965 000 13890 FUSE 4A/250V 215004 111111111
FH601 4822 256 10461 FUSE HOLDER MSF-015 111111111
FH602 4822 256 10461 FUSE HOLDER MSF-015 111111111
PB1 9965 000 18122 POWER PCB HOLDER T6400RA 111111111
PB4 9965 000 18111 13V POW HEAT SINK PAL PHKT6400RA 111111111
PB5 9965 000 18123 13V P H/S PAL PHM ASSEMBLY T6400RA 111111111
PL1 9965 000 08646 SCREW, P-TIGHT 3X12 WASHER HEAD+ 111111111
PL2 9965 000 12171 SCREW, B-TIGHT M3X8 BIND HEAD+ 111111111
PS602
h
9965 000 13896 THERMISTOR ZPB31BL9R0A 111111111
SA601
h
9965 000 20946 SURGE ABSORBER 470V+-10PER 111111111
T551
h
9965 000 18124 FLYBACK TRANS BSC23-2603S 111111111
T552
h
9965 000 13904 H0RIZONTAL DRIVE TRANS LP2-005 111111111
T601
h
9965 000 24198 SWITCHING TRANS 04705 111111
T601
h
9965 000 24202 SWITCHING TRANS 04703 1 1 1
TM601 9965 000 22702 TAB 42018 111111111
TM602 9965 000 22702 TAB 42018 111111111
TP501 PCB JUMPER D0.6-P7.5 111111111
1-14-31
