12 NC Description
14PV385/39
14PV135/07
14PV235/01
14PV235/58
14PV385/07
14PV135/01
14PV135/58
14PV235/07
14PV385/01
TP502 PCB JUMPER D0.6-P7.5 111111111
TP503 PCB JUMPER D0.6-P15.0 111111111
TP504 PCB JUMPER D0.6-P15.0 111111111
VR601
h
9965 000 23550 CARBON P.O.T. 20K OHM B 111111111
CRT CBA
CAPACITORS
C501 CERAMIC CAP.(AX) B K 220PF/50V 111111111
C502 CERAMIC CAP.(AX) B K 220PF/50V 111111111
C503 CERAMIC CAP.(AX) B K 220PF/50V 111111111
C504 CERAMIC CAP. B K 1000PF/2KV 111111111
C505 ELECTROLYTIC CAP. 1UF/50V M H7 111111111
CONNECTORS
CN501 9965 000 13911 PIN CONNECTOR 005P-5100 111111111
CN502 9965 000 05247 CONNECTOR BASE, 4P TUC-P04P-B1 111111111
COILS
L501 PCB JUMPER D0.6-P5.0 111111111
TRANSISTORS
Q501 4822 130 60578 TRANSISTOR 2SC2482 TPE6 111111111
Q502 4822 130 60578 TRANSISTOR 2SC2482 TPE6 111111111
Q503 4822 130 60578 TRANSISTOR 2SC2482 TPE6 111111111
RESISTORS
R501
h
4822 053 10183 METAL OXIDE FILM RES. 1W J 18K OHM 111111111
R502
h
4822 053 10183 METAL OXIDE FILM RES. 1W J 18K OHM 111111111
R503
h
4822 053 10183 METAL OXIDE FILM RES. 1W J 18K OHM 111111111
R504 CARBON RES. 1/4W J 1.5K OHM 111111111
R505 CARBON RES. 1/4W J 1.5K OHM 111111111
R506 CARBON RES. 1/4W J 1.5K OHM 111111111
R507 CARBON RES. 1/4W J 1.5K OHM 111111111
R510 CARBON RES. 1/4W J 1.5K OHM 111111111
R511 PCB JUMPER D0.6-P5.0 111111111
R512 PCB JUMPER D0.6-P5.0 111111111
R513 PCB JUMPER D0.6-P5.0 111111111
R514 CARBON RES. 1/4W J 1.5K OHM 111111111
R515 CARBON RES. 1/4W J 120K OHM 111111111
R516 CARBON RES. 1/4W J 15 OHM 111111111
R517 CARBON RES. 1/4W J 560 OHM 111111111
R518 CARBON RES. 1/4W J 120K OHM 111111111
R519 CARBON RES. 1/4W J 15 OHM 111111111
R520 CARBON RES. 1/4W J 560 OHM 111111111
R521 CARBON RES. 1/4W J 120K OHM 111111111
R522 CARBON RES. 1/4W J 15 OHM 111111111
R523 CARBON RES. 1/4W J 560 OHM 111111111
JK501
h
9965 000 13913 CRT SOCKET ISMS01S 111111111
TEXT CBA
CAPACITORS
C901 ELECTROLYTIC CAP. 22UF/50V M 111111
C902 CERAMIC CAP.(AX) B K 100PF/50V 111111
C903 ELECTROLYTIC CAP. 0.1UF/50V M 111111
C904 ELECTROLYTIC CAP. 0.1UF/50V M 111111
C905 CERAMIC CAP.(AX) Y M 0.01UF/16V 111111
C906 ELECTROLYTIC CAP. 100UF/10V M 111111
C916 CERAMIC CAP.(AX) CH J 18PF/50V 111111
C917 CERAMIC CAP.(AX) CH J 18PF/50V 111111
C920 CERAMIC CAP.(AX) Y M 0.01UF/16V 111111
C921 ELECTROLYTIC CAP. 100UF/10V M 111111
C922 ELECTROLYTIC CAP. 100UF/10V M 111111
C923 ELECTROLYTIC CAP. 100UF/10V M 111111
C926 CERAMIC CAP.(AX) Y M 0.01UF/16V 111111
1-14-32
