Philips 14PV225 - Parts Lists; Electrical Parts List

NOTES:
C…..±0.25% D…..±0.5% F…..±1%
G…..±2% J…..±5% K…..±10%
M…..±20% N…..±30% Z…..+80/-20%
ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
MAIN CBA
1111111111111
JUNCTION A CBA
1111111111111
JUNCTION B CBA
1111111111111
JUNCTION C CBA
1111111111111
SENSOR CBA
1111111111111
POWER CBA
1111111111111
CRT CBA
1111111111111
TEXT CBA
1111111
C001 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 1111111111111
C002 9965 000 14863 ELECTROLYTIC CAP. 47UF/25V M 1111111111111
C006 9965 000 13908 ELECTROLYTIC CAP. 1UF/50V M 1111111111111
C007 CHIP CERAMIC CAP. B K 0.01UF/50V 1111111111111
C008 ELECTROLYTIC CAP. 1UF/50V M 1111111111111
C009 PCB JUMPER D0.6-P5.0 1111111111111
C012 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 1111111111111
C151 ELECTROLYTIC CAP. 330UF/16V M 1111111111111
C152 CERAMIC CAP.(AX) X M 2200PF/16V 1111111111111
C154 ELECTROLYTIC CAP. 470UF/16V M 1111111111111
C155 ELECTROLYTIC CAP. 0.22UF/50V M H7 1111111111111
C156 CHIP CERAMIC CAP. B K 4700PF/50V 1111111111111
C157 ELECTROLYTIC CAP. 10UF/25V M H7 1111111111111
C160 CHIP CERAMIC CAP. CH J 390PF/50V 1111111111111
C203 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 1111111111111
C205 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 1111111111111
C207 ELECTROLYTIC CAP. 1UF/50V M H7 1111111111111
C208 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 1111111111111
C209 CHIP CERAMIC CAP. CH J 22PF/50V 1111111111111
C210 CHIP CERAMIC CAP. CH J 22PF/50V 1111111111111
C211 ELECTROLYTIC CAP. 47UF/6.3V M H7 1111111111111
C212 CHIP CERAMIC CAP.(MELF) F Z 0.01UF/16V 1111111111111
C213 ELECTROLYTIC CAP. 47UF/6.3V M H7 1111111111111
C214 ELECTROLYTIC CAP. 330UF/6.3V M 1111111111111
C217 CHIP CERAMIC CAP. CH D 10PF/50V 1111111111111
C218 CHIP CERAMIC CAP. CH D 10PF/50V 1111111111111
C221 ELECTROLYTIC CAP. 47UF/6.3V M H7 1111111111111
CAPACITORS
PRODUCT SAFETY NOTE: Products marked with a h
have special characteristics important to safety.
Before replacing any of these components, read carefully
the product safety notice in this service manual.
Don’t degrade the safety of the product through improper servicing.
MMA CBA
Consists of the following
MAIN CBA
14PV120/07 14PV125/01 14PV125/07 14PV125/39 14PV125/58 14PV225/01 14PV225/07 14PV225/39 14PV422/58 14PV225/58 14PV422/01 14PV422/07 14PV422/39
1-14-18
