STANDARD MAINTENANCE
[ 14PV120/07, 14PV125/ ( 01, 07, 39, 58 ), 14PV225/ ( 01, 07, 39, 58 ),
14PV422/ ( 01, 07, 39, 58 ), 14PV425/07 ]
Service Schedule of Components
Notes:
1.Clean all parts for the tape transport (Upper Drum with Video Head / Pinch Roller / Audio Control Head / Full
Erase Head) using 90% lsopropyl Alcohol.
2.After cleaning the parts, do all DECK ADJUSTMENTS.
3.For the reference numbers listed above, refer to Deck Exploded Views.
H: Hours : Check I: Change
Deck Periodic Service Schedule
Ref.No. Part Name 1,000 H 2,000 H 3,000 H 4,000 H
B2
Cylinder Assembly
II
B3 Loading Motor Assembly
I
B8
Pulley Assembly
II
B587
Tension Lever Assembly
II
B31 AC Head Assembly
I
B573,B574
Reel (SP)(D2), Reel (TU)(D2)
I
B37
Capstan Motor
II
B52 Cap Belt
II
B73
FE Head
I
B133,B134
Idler Gear, Idler Arm
II
B410 Pinch Arm Assembly II
B414
M Brake (SP) Assembly
II
B416
M Brake (TU) Assembly
II
B525 LDG Belt II
B569
Cam Holder (F)
II
