Philips 14PV225 - Page 43

MECHANICAL PARTS LIST
Pos.
Pos.
Expl. View
h
12 NC Description
14PV120/07 14PV125/01 14PV125/07 14PV125/39 14PV422/07 14PV422/58 14PV225/39 14PV422/01 14PV422/39 14PV125/58 14PV225/01 14PV225/07 14PV225/58
0071 A12 3143 027 50201 POWER BUTTON PH004 1
1010 SP151 9965 000 18085 SPEAKER ASSY 1 111111111111
0002 B4 4822 402 10174 BRACKET ==>14" 1 111111111111
0004 B1 3143 021 20031 TENSION SPRING 1 111111111111
0030 B3 3143 021 20011 SCREENING 1 111111111111
0015 3143 027 50351 CABLE CLAMP 1 111111111111
0054 B2 SCREW ===>CRT 1 111111111111
0057 L8 FLAT HEAD SCREW 4X18 1 111111111111
0058 TL1 SHIELD PLATE SCREW M3X4 1 111111111111
1100 CRT A34EAC01X71 1 111111111111
1B1 DECK ASSEMBLY 1 111111111111
TB1 TRAY CHASSIS T6400RA 1 111111111111
TB2 TOP COVER T6300RA 1 111111111111
TB10 9965 000 18086 RCA HOLDER T6400RA 1 111111111111
TB23 BOTTOM PLATE T6300RA 1 111111111111
TL1 9965 000 08646
SCREW, P-TIGHT
3X12 WASHER HEAD+
1111111111111
TL14 9965 000 12171
SCREW, B-TIGHT
M3X8 BIND HEAD+
1111111111111
TL18 9965 000 13027
SCREW, P-TIGHT
M3X8 BIND HEAD+
1111111111111
PACKING
0450 S1 BOX FOLDED 14PV120 1
0450 S1 BOX FOLDED 14PV125 1111
0450 S1 BOX FOLDED 14PV22X 1 1 1 1
0450 S1 BOX FOLDED 14PV42X 1 1 1 1
0453 S2 STYROFOAM TOP A 1 11111111
0453 S2 STYROFOAM TOP B 1 1 1 1
0454 S2 STYROFOAM BOTTOM A 1 11111111
0454 S2 STYROFOAM BOTTOM B 1 1 1 1
0455 X1 BAG (==>MAINS CORD) 1 111111111111
0469 S6 TOPFOIL 1 111111111111
0471 STRETCHFOIL 500/15 1 111111111111
0150 X3 9965 000 18084 RC RT350/101 1
0150 X3 9965 000 18138 RC RT350/111 1111 1111
0150 X3 9965 000 18139 RC RT351/111 1 1 1 1
TEST TAPES
0001 3143 023 20011 TEST TAPE FL6K(S) 1 111111111111
0002 3143 023 20021 TEST TAPE FL6NS8 1 111111111111
0003 3143 023 20031 TEST TAPE FSLT-120 1 111111111111
0004 3143 023 20041 TEST TAPE FL6M 1 111111111111
